| Type: | Amateur VHF transceiver |
| Frequency range: | TX: 144-146 MHz (Europe) TX: 144-148 MHz (USA) RX: 110-180 / 300-520 / 800-999 MHz |
| Mode: | TX: FM RX: AM/FM |
| RF Power output: | Hi: 70 W Mid1: 50 W Mid2: 25 W Lo: 10 W |
| Receiver system: | N/A |
| Sensitivity: | Main: 0.2 uV (12 dB SINAD) Sub: 0.25 uV (12 dB SINAD) |
| Selectivity: | 15 KHz (-6 dB), 28 KHz (-60 dB) |
| Image rejection: | >70 dB |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 0.5-0.8 A TX: Max 15 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 140*40*180 mm |
| Weight: | 1.25 Kg |
| Manufactured: | 19xx-19xx (Discontinued) |
| Other: | 81 memories. DCS & ARTS. 9K6 packet ready. Twin RX |
 FT-3000 - user manual | 4587 kB |
