| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | 144-146 / 430-440 MHz (10 m/10 W (CRF-081) or 23 cm/10 W (CRF-301) options) (5/10/12.5/20/25/50/100 KHz and 1 MHz steps) |
| Mode: | FM |
| RF Power output: | Hi: 10/10 W Mid: 5/5 W Lo: 1/1 W |
| Receiver system: | 2 m/70 cm: Dual-conversion superheterodyne 1st IF: 21.8 MHz (2 m), 47.05 MHz (70 cm) 2nd IF: 455 KHz (2 m/70 cm) |
| Sensitivity: | 0.16 uV (12 dB SINAD) |
| Selectivity: | 12 KHz (-6 dB), 24 KHz (-60 dB) |
| Image rejection: | 2 m: 65 dB 70 cm: 60 dB |
| Voltage: | 13.8 VDC or mains |
| Current drain: | RX: 1.3 A TX: Max 4.5 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 362*109*330 mm |
| Weight: | 11 Kg |
| Manufactured: | Japan, 1991-199x |
| Other: | Remote control. 33 memories. CTCSS and DTMF options. |
 standard c50_c50d.pdf | 1637 kB |
