Ricevitore HF
| Type: | HF receiver |
| Frequency range: | 10-80 m |
| Mode: | AM/SSB/CW (FM option) |
| Receiver system: | ? conversion superheterodyne |
| Sensitivity: | 0.5 uV (10 dB S/N) |
| Selectivity: | SSB: 2.1 KHz (-6 dB) |
| Image rejection: | >50 dB |
| Voltage: | Mains |
| Current drain: | ? |
| Impedance: | 50-70 ohms, SO-239 |
| Dimensions (W*H*D): | 380*180*330 mm |
| Weight: | 12 Kg |
| Manufactured: | 1965-196x |
| Other: | New price 1965 in West Germany: 995.- DM |
 FR-100B_schematic_diagram.pdf | 747 kB |
