veicolare VHF/UHF
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | 144-146 / 430-440 MHz (Europe) 144-148 / 430-450 MHz (USA) |
| Mode: | FM |
| RF Power output: | Hi: 50/35 W Lo: 5/5 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 600 mA TX: Max 11.5 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 140*40*155 mm |
| Weight: | 1.0 Kg |
| Manufactured: | 1993-199x (Discontinued) |
| Other: | Twin RX New price 1993 in Sweden: 8086:- SEK |
 ft-5100 - user manual | 2127 kB |
 FT-5100 - mod | 14 kB |
| FT-5100 - service manual | 5336 kB |
