| Type: | Amateur HF/VHF transceiver |
| Frequency range: | TX: 10-160 m + WARC / 50-54 MHz RX: 0.1-30 MHz |
| Mode: | AM/SSB/CW (FM option) |
| RF Power output: | SSB/CW: Max 100 W AM: 25 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 2.2 A TX: Max 22 A |
| Impedance: | 16.7-150 ohms with a built-in auto-AT |
| Dimensions (W*H*D): | 410*135*316 mm |
| Weight: | 11.5 Kg |
| Manufactured: | 199x-200x (Discontinued) |
| Other: | DSP.127 memories. RS-232C. Twin RX. |
 FT-920_italiano_errata_corrige.pdf | 42 kB |
| FT-920_manuale_utente_italiano.pdf | 10279 kB |
 FT-920_modifica.zip | 2 kB |
| FT-920_schema_elettrico.pdf | 1897 kB |
| FT-920_service_manual.pdf | 44102 kB |
