| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | TX: 50-54 / 144-146 / 430-440 MHz (Europe) TX: 50-54 / 144-148 / 222-225 / 440-450 MHz (USA) RX: 0.5-999 MHz (Cellular blocked in the US) |
| Mode: | TX: AM/FM RX: AM/FM/WFM |
| RF Power output: | Hi: 5/5/5 W Low3: 2.5/2.5/2.5 W Low2: 1/1/1 W Low1: 0.5/0.5/0.5 W 0.3 W (220 MHz, FM), 1 W (50 MHz, AM) |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 7.2 VDC (internal), 10-16 VDC (external) |
| Current drain: | RX: 25-200 mA TX: 0.6-1.8 A |
| Impedance: | 50 ohms, SMA |
| Dimensions (W*H*D): | 60*90*28 mm |
| Weight: | 250 gr |
| Manufactured: | 2002-200x |
VX-7 Commander
Programming software for the Yaesu VX-7 and VX-7R
Programming software for the Yaesu VX-7 and VX-7R
Features:
- Edit, cut, copy, paste, delete, move Main, One-Touch, Scan Edge, Home, and VFO Memories
- Edit Memory Groups
- Edit Hyper Memories
- Edit the VX-7 Set Mode settings
- Software modifications for MARS/CAP and Freeband
- Software modification to enable the "My Menu" feature
- Import from csv files and ARRL TravelPlus (TM) files
- Import data from VX-5 EVE files and RDF files
- Open VX-7 .RDF (RT Systems ADMS-1G) files (must save as .vx7 files)
- Recover deleted memories, even if VX-7 is reset
- Custom Icon Editor, Custom Font Editor
- Print memory range to default printer
- Two selectable interfaces for editing memories
 VX-7R - manuale utente in italiano a libretto | 2703 kB |
| VX-7R - user manual english | 2475 kB |
| VX-7R - service manual | 11357 kB |
| VX-7R - ARRL Test | 217 kB |
| VX-7R - manuale utente in italiano | 3421 kB |
 VX-7R - modifiche | 63 kB |
| Programming software for the Yaesu VX-7 and VX-7R | 2446 kB |
