| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | TX: 144-146 / 430-440 MHz RX: 118-174 / 300-520 / 800-999 MHz (after modification) |
| Mode: | TX: FM RX: AM/FM |
| RF Power output: | Hi: 50/35 W Mid: 10/10 W Lo: 5/5 W |
| Sensitivity: | 0.16 uV (12 dB SINAD) |
| Selectivity: | 12 KHz (-6 dB), 28 KHz (-60 dB) |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC +/- 15% |
| Current drain: | RX: Max 1 A TX: Max 11 A |
| Impedance: | 50 ohms, N-type |
| Dimensions (W*H*D): | 140*40*189 mm |
| Weight: | 1.2 Kg |
| Manufactured: | 1998-199x |
| Other: | 180 memories with alpha tags. CTCSS/PL. 1K2/9K6 bd packet ready |
 tm-g707-ctcss-decode-mod.pdf | 3707 kB |
| TM-G707 - manuale utente in italiano | 4985 kB |
| TM-G707_user_manual.pdf | 3383 kB |
 TM-G707 - RX TX espansion | 0.6 kB |
