| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | TX: 144-146 / 430-440 MHz (Europe) RX: 118-999 MHz |
| Mode: | TX: FM/FM-N RX: AM/FM/FM-N |
| RF Power output: | Hi: 50/35 W Mid-Hi: 20/20 W Mid-Lo: 10/10 W Lo: 5/5 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max ? A TX: Max 12 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 140*40*146 mm (Transceiver), 140*70*34 mm (Head) |
| Weight: | 1.15 Kg (Transceiver), 290 gr (Head) |
| Manufactured: | Japan, 2000-2002 (Discontinued) |
| Other: | Twin RX. External video input for display on the TFT New price 2001 in Sweden: 7700:- SEK |
 IC-2800H - manuale english | 969 kB |
| IC-2800H - manual service english | 3479 kB |
