| Type: | Amateur HF/VHF transceiver |
| Frequency range: | TX: 10-160 m + WARC / 50-54 / 144-148 MHz RX: 0.03-60 / 108-174 MHz |
| Mode: | AM/FM/SSB/CW/RTTY |
| RF Power output: | 5-100 W (AM: 5-40 W) |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 2.2-3 A TX: Max 23 A |
| Impedance: | 50 ohms, 3 x SO-239 |
| Dimensions (W*H*D): | 287*120*316 mm |
| Weight: | 9 Kg |
| Manufactured: | Japan, 2001-2009 (Discontinued) |
| Other: | 32 bit DSP, CI-V Auto-ATU: 17-150 ohms (HF), 20-125 ohms (6 m) |
 IC-746PRO_ARRL-test.pdf | 1142 kB |
| IC-746PRO_user_manual.pdf | 5562 kB |
