| Type: | Amateur UHF transceiver |
| Frequency range: | TX: 430-450 MHz RX: 350-512 MHz |
| Mode: | FM |
| RF Power output: | Hi: 35 W Mid: 10 W Lo: 5 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 11.7-15.8 VDC |
| Current drain: | RX: 400-600 mA TX: Max 10 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 142*40*174 mm |
| Weight: | 1 Kg |
| Manufactured: | 2001-200x (discontinued) |
| Other: | 100 memories. 1K2/9K6 TNC option, GPS input for APRS. CTCSS, DCS. Theft alarm. 20F3 DV option (requires at least two similarly equipped radios) |
 Alinco_DR-135_DR-235_DR-435_service_manual.pdf | 5238 kB |
| DR-135_235_435_Dealer_Manual.pdf | 201 kB |
| dr-135_435mk3_user_manual.pdf | 1195 kB |
