Veicolare VHF/UHF
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | 144-146 / 430-440 MHz (Europe & Asia) (12.5/25 KHz steps) |
| Mode: | FM |
| RF Power output: | Hi: 25/25 W Lo: 3/3 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 600 mA TX: Max 7 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 150*50*168 mm |
| Weight: | 1.5 Kg |
| Manufactured: | Japan, 1985-198x (Discontinued) |
 FT-2700RH - manuale utente in italiano | 2402 kB |
| FT-2700RH - block diagram | 95 kB |
| FT-2700RH - schema | 379 kB |
| FT-2700RH - service manual | 9294 kB |
| FT-2700RH - user manual | 10772 kB |
