Type: | Amateur HF transceiver |
Frequency range: | 10-80 m |
Mode: | AM/SSB/CW |
RF Power output: | 150 W (PEP input) |
Receiver system: | N/A |
Sensitivity: | N/A |
Selectivity: | N/A |
Image rejection: | N/A |
Voltage: | 12 VDC or mains |
Current drain: | RX: Max 500 mA @ 12 VDC TX: Max 11 A @ 12 VDC |
Impedance: | 50-75 ohms |
Dimensions (W*H*D): | 10.5 x 6 x 13" |
Weight: | ? Kg |
Manufactured: | 1966-196x (Discontinued) |
Other: | 3 tubes. 2 x 6JM6 final |
