Type: | Amateur HF/VHF/UHF transceiver |
Frequency range: | TX: 28-29.7 / 50-54 / 144-146 / 430-440 MHz (Europe) TX: 28-29.7 / 50-54 / 144-148 / 430-450 MHz (USA) RX: 28-29.7 / 50-54 / 108-180 / 320-480 / 700-958 MHz (Cellular blocked in the US) |
Mode: | TX: FM/NFM (15 / 7.5 KHz BW) RX: AM/FM/NFM |
RF Power output: | Hi: 50/50/50/35 W Mid1: 20/20/20/20 W Mid2: 10/10/10/10 W Lo: 5/5/5/5 W |
Receiver system: | N/A |
Sensitivity: | Better than 0.2 uV (12 dB SINAD) |
Selectivity: | 12 KHz (-6 dB), 30 KHz (-60 dB) |
Image rejection: | N/A |
Voltage: | 13.8 VDC +/- 15% |
Current drain: | RX: 0.5-? A TX: Max 8.5 A |
Impedance: | 50 ohms, SO-239 (N-type for Europe) |
Dimensions (W*H*D): | 140*42*168 mm |
Weight: | 1 Kg |
Manufactured: | 2002-200x |
Other: | ARTS, CTCSS and DCS. WIRES-compatible (internet connection). 800 memories. 1200/9600 bps packet jack. Twin RX. Maldol makes a suitable mobile antenna for this radio. |
