SPECIFICATIONS
| Type: | Amateur VHF transceiver |
| Frequency range: | 144-146 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5 W Lo: 0.5 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 6-16 VDC |
| Current drain: | RX: 16-100 mA TX: Max 1.2 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 58*138*30 mm (with PB-6) |
| Weight: | 400 gr (with PB-6) |
| Manufactured: | 1987-19xx (Discontinued) |
| Other: | New price 1988 in Sweden: 2800:- SEK |
 TH-25 - User manual | 1939 kB |
 TH-25-45_modifications.zip | 4 kB |
| TH-25_service_manual.pdf | 8939 kB |
