| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: | 0.5-905 MHz (Europe) 0.5-824 MHz + NTSC-TV (USA) (5 / 12.5 / 20 / 25 KHz steps) |
| Mode: | AM/FM/WFM |
| Receiver system: | N/A |
| Sensitivity: | NFM >60 MHz: 3 uV (12 dB SINAD) WFM 83 MHz: 1 uV (12 dB SINAD) AM MW: <10 uV (10 dB S/N) AM V/UHF: 5 uV (10 dB S/N) |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 11-16 VDC |
| Current drain: | Max 1 A |
| Impedance: | 50-300 ohms |
| Dimensions (W*H*D): | 180*50*158 mm |
| Weight: | 1.5 Kg |
| Manufactured: | Japan, 1988-19xx (Discontinued) |
| Other: | 100 memories. New price 1988 in Sweden: 5100:- SEK |
 RZ-1_manuale_utente_italiano.PDF | 2572 kB |
| RZ-1_service_manual.pdf | 2126 kB |
| RZ-1_user_manual.pdf | 915 kB |
