| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | 144-146 / 430-440 MHz |
| Mode: | AM/FM/SSB/CW |
| RF Power output: | 10 W/10 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC or mains |
| Current drain: | RX: ? mA TX: Max ? A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | ? |
| Weight: | ? |
| Manufactured: | 1979-19xx (Discontinued) |
| Other: | Vox, NB, RIT, Digital readout |
 TS-770_modifications.zip | 0.9 kB |
 TS-770_schematic_diagram.pdf | 595 kB |
| TS-770_service_manual.pdf | 18548 kB |
| TS-770_user_manual.pdf | 1617 kB |
