Current drainRx: 20-100 mA
Tx: Max 2 A
Tx: Max 2 A
Dimensions (W*H*D)67*173*37 mm
Frequency range430-440 MHz
Impedance50 ohms, BNC
Manufactured19xx-19xx
ModeFM
RF Power outputHi: Max 5 W (depending on voltage)
Lo: 0.5 W
Lo: 0.5 W
Voltage6.3-16 VDC
Weight540 gr (with PB-2 and antenna)
 TH-405_schematic_diagram.pdf | 565 kB |
