| Frequency range: | 430-440 MHz |
| Mode: | FM |
| RF Power output: | Hi: 2-5 W (depending on voltage), Lo: 0.5 W, El: 20 mW |
| Voltage: | 7.2-16 VDC |
| Current drain: | RX: Max 57 mA, TX: Max 1.6 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 49.5*115.8*37.8 mm |
| Weight: | 330 gr (with PB-13, antenna, handstrap and belt hook) |
| Manufactured: | 1992-19xx |
| Other: | RX: 118-174 / 430-440 MHz New price 1992 in Sweden: 3719:- SEK |
 TH-28_TH-48_user_manual.pdf | 1121 kB |
