| Type: | Amateur VHF transceiver |
| Frequency range: | 144-146 MHz (Europe) 144-148 MHz (USA) |
| Mode: | FM/SSB/CW |
| RF Power output: | Hi: 10 W Lo: 1 W |
| Receiver system: | Single conversion superheterodyne (SSB/CW) Dual conversion superheterodyne (FM) 1st IF: 10.695 MHz 2nd IF: 455 KHz (FM) |
| Sensitivity: | FM: 0.25 uV (12 dB SINAD) SSB/CW: 0.25 uV (10 dB S/N) |
| Selectivity: | FM: 12 KHz (-6 dB), 25 KHz (-60 dB) SSB/CW: 2.2 KHz (-6 dB), 4.8 KHz (-60 dB) |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC +/-15% |
| Current drain: | RX: 400 mA (No input) TX: 1.3 - 2.9 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 170*68*234 mm |
| Weight: | 2.5 Kg |
| Manufactured: | Japan, 19xx-19xx (Discontinued) |
| Other: | 5 memories, scanning. NB, RIT |
 TR-9000_user_manual.pdf | 5043 kB |
