| Type: | Amateur HF/VHF transceiver |
| Frequency range: | TX: 10-160 m + WARC / 50-54 MHz RX: 0.5-30 MHz / 50-54 MHz |
| Mode: | AM/FM/SSB/CW |
| RF Power output: | Max 100/100 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: ? A TX: ? A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 270*96*271 mm |
| Weight: | ? Kg |
| Manufactured: | 1997-19xx (Discontinued) |
| Other: | DSP |
 TS-570 Brochure.pdf | 1432 kB |
| TS-570_manuale_utente_italiano.pdf | 3148 kB |
| TS-570_schematic_diagram.pdf | 1585 kB |
| TS-570_service_manual.pdf | 3357 kB |
| TS-570_user_manual.pdf | 2459 kB |
