ricevitore ampio spettro (scanner) doppio ascolto gestibile da PC
| Type: | HF/VHF/UHF/SHF receiver/scanner |
| Frequency range: | 0.01-3300 MHz |
| Mode: | AM/FM/WFM/SSB/CW (No AM/SSB/CW above 1300 MHz) |
| Sensitivity: | AM (10 dB S/N) 0.495-1.8 MHz: 25 uV 1.8-50 MHz: 2.5 uV 50-700 MHz: 2 uV 700-1300 MHz: 2.5 uV FM (12 dB SINAD) 1.8-50 MHz: 0.63 uV 50-700 MHz: 0.5 uV 700-1300 MHz: 0.63 uV 1300-2300 MHz: 5.6 uV 2300-3000 MHz: 18 uV WFM (12 dB SINAD) 50-700 MHz: 1.4 uV 700-1300 MHz: 1.8 uV 1300-2300 MHz: 18 uV 2300-3000 MHz: 56 uV SSB/CW (10 dB S/N) 0.495-1.8 MHz: 5 uV 1.8-50 MHz: 0.5 uV 50-700 MHz: 0.4 uV 700-1300 MHz: 0.5 uV |
| Selectivity: | AM/FM: 6 KHz (-6 dB), 15 KHz (-60 dB) WFM: 50 KHz (-6 dB), 230 KHz (-60 dB) SSB/CW: 2.8 KHz (-6 dB) |
| Image rejection: | N/A |
| Voltage: | 12 VDC +/- 15% |
| Current drain: | Max 1.5 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | Box: 146*41*206 mm Panel: 140*50*28 mm |
| Weight: | Box: 1.35 Kg Panel: 250 gr |
| Manufactured: | Japan, 2006-200x |
| Other: | CTCSS/DTCS. Dual watch and diversity reception. DSP (UT-106) and D-Star (UT-118) options Windows software for computer control via USB connector |
 IC-PCR2500 - user manual english | 8925 kB |
| IC-PCR2500_brochure.pdf | 619 kB |
