Type: | HF/VHF/UHF receiver/scanner |
Frequency range: | 0.5-1300 MHz (0.1-100 KHz steps) |
Mode: | AM/FM/WFM/SSB/CW |
Sensitivity: | AM 0.5-5 MHz: 1.6 uV 5-200 MHz: 1.0 uV 200-340 MHz: 1.6 uV 340-700 MHz: 1.4 uV 700-800 MHz: 2.0 uV 800-1300 MHz: 1.6 uV FM 0.5-5 MHz: 0.5 uV 5-200 MHz: 0.32 uV 200-340 MHz: 0.45 uV 340-700 MHz: 0.35 uV 700-800 MHz: 0.79 uV 800-1300 MHz: 0.5 uV WFM 75-200 MHz: 1.0 uV 200-340 MHz: 2.2 uV 340-700 MHz: 1.3 uV 700-800 MHz: 2.0 uV 800-900 MHz: 1.6 uV SSB/CW 0.5-5 MHz: 0.4 uV 5-200 MHz: 0.25 uV 200-340 MHz: 0.4 uV 340-700 MHz: 0.32 uV 700-800 MHz: 0.63 uV 800-1300 MHz: 0.4 uV |
Selectivity: | AM/FM: >15 KHz (-6 dB) WFM: >150 KHz (-6 dB) SSB: >4 KHz (-6 dB) |
Image rejection: | N/A |
Voltage: | 4.8-6 VDC (4*R6/AA) or 4.8-16 VDC external |
Current drain: | 38-180 mA |
Impedance: | 50 ohms, BNC |
Dimensions (W*H*D): | 58*130*31 mm |
Weight: | 310 gr |
Manufactured: | Japan, 1996-1999 (Discontinued) |
Other: | 1000 memories. CI-V. VSC. Bandscope New price 2001 in Sweden: 4990:- SEK |
