| Type: | Amateur VHF/UHF transceiver |
| Frequency range: | 144-146 / 430-440 MHz |
| Mode: | FM |
| RF Power output: | Hi: 5.5/5 W Lo: 1/1 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 7.2-13.2 VDC battery pack or 12-15 VDC external |
| Current drain: | RX: 10-250 mA TX: Max 2.2 A |
| Impedance: | 50 ohms, BNC |
| Dimensions (W*H*D): | 65*159*35 mm (with BP-3) |
| Weight: | 510 gr (with BP-3) |
| Manufactured: | 1988-19xx (Discontinued) |
| Other: | 20 memories New price 1988 in Sweden: 4995:- SEK |
| Related documents: |
 IC-32A - manuale italiano | 3541 kB |
 IC-32_modifications.zip | 3 kB |
| IC-32_schematic_diagram.pdf | 16630 kB |
| IC-32_user_manual.pdf | 4124 kB |
| IC-32 - Service Manual | 2715 kB |
