| Type: | Amateur VHF transceiver |
| Frequency range: | 144-146 MHz |
| Mode: | FM/SSB/CW |
| RF Power output: | Hi: 10 W Lo: ? W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: 0.7 A TX: Max 2.8 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 157*88*220 mm |
| Weight: | 2.66 Kg |
| Manufactured: | Japan, 1977-19xx (Discontinued) |
 IC-245_manuale_utente_italiano.pdf | 3360 kB |
| IC-245_schematich_diagram.pdf | 549 kB |
| IC-245_user_manual.pdf | 3360 kB |
