| Type: | Amateur VHF transceiver |
| Frequency range: | TX: 144-146 MHz (Europe) TX: 144-148 MHz (USA) RX: 136-174 MHz |
| Mode: | FM |
| RF Power output: | Hi: 50 W Lo3: 25 W Lo2: 10 W Lo1: 5 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 0.5 A TX: Max 10.5 A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 140*40*155 mm |
| Weight: | 1 Kg |
| Manufactured: | Japan, 1990-199x (Discontinued) |
| Other: | PLL IC: PLL2001 New price 1990 in Sweden: 3800:- SEK |
 IC-229_mod.ifications.zip | 6 kB |
 IC-229_schematic_diagram.pdf | 784 kB |
| IC-229_service_manual.pdf | 14595 kB |
| IC-229_user_manual.pdf | 3235 kB |
