| Frequency range: | 144-146 MHz (12.5/25 KHz steps) |
| Mode: | FM |
| RF Power output: | Hi: 25 W Lo: 5 W |
| Receiver system: | N/A |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | >N/A |
| Voltage: | 13.8 VDC |
| Current drain: | RX: Max 600 mA TX: Max 6 A |
| Impedance: | 50 ohms |
| Dimensions (W*H*D): | 140**38*177 mm |
| Weight: | 1.2 Kg |
| Manufactured: | Japan, 1983-198x (Discontinued) |
| Other: | New price 1984 in Sweden: 3550:- SEK |
 IC-27_modifications.zip | 0.7 kB |
 IC-27_schematic_diagram.pdf | 2524 kB |
| IC-27_user_manual.pdf | 4030 kB |
