144-146 MHz
Usable temperature range
: -10oC to +60oC(+14oF to + 140oF)
Tuning steps
: 5,10,12.5,15,20,25,30, or 50 kHz
Dial select steps
: 100 kHz,or 1 MHz
Number of channels
: 43 (40 regular channels, 1 call channel and 2 scan edge channels)
Frequency stability
: +/- 15 ppm (0oC to + 60oC;
+32oF to +144oF)
Current drain(at 13.5 V DC,typical)
: Transmit High 2.0 A(2GX),1.8A(4Gx)
Low 0.9 A
Receive Rated audio output 250 mA
Power saved 35 mA(average)
External DC power supply
: 6 to 16 V DC (negative ground)
Dimensions(with BP-160)
(projections not included)
: 57(W) x 125(H) x 35(D) mm
2.2(W) x 4.9(H) x 1.4(D) in
Weight (with BP-160)
: IC-2GXAT/ET 365g(12.9 oz)
IC-2GXA/E 355g(12.5 oz)
IC-4GXAT/ET 345g(12.2 oz)
IC-4GXA/E 340g(12.0 oz)
