| Type: | Amateur HF transceiver |
| Frequency range: | TX: 10-160 m + WARC RX: 0.1-30 MHz |
| Mode: | AM/FM/SSB/CW |
| RF Power output: | 100 W |
| Sensitivity: | N/A |
| Selectivity: | N/A |
| Image rejection: | N/A |
| Voltage: | Mains |
| Current drain: | RX: ? mA TX: Max ? A |
| Impedance: | 50 ohms, SO-239 |
| Dimensions (W*H*D): | 424*150*390 mm |
| Weight: | 17.5 Kg |
| Manufactured: | Japan, 1989-1990 (Discontinued) |
| Other: | Built-in auto-AT New price 1994 in Sweden: 29310:- SEK |
 IC-765_modifications.zip | 2408 kB |
 IC-765_service_manual.pdf | 31540 kB |
