| VHF 134-174 MHz | VX-821E VHF | |
| VHF 134-174 MHz | VX-824E VHF | |
| VHF 134-174 MHz | VX-829E VHF | |
| UHF 400-470 MHz | VX-821E UHF | |
| UHF 400-470 MHz | VX-824E UHF | |
| UHF 400-470 MHz | VX-829E UHF |
Features:
- 200 Channel Capacity
- Lightweight & Compact Size
- Submersible to IP57 specifications
- 5W Power Output (selectable to 2.5, 1 & 0.25 watt power levels)
- Rugged Construction – MIL-STD 810 C/D/E
- CTCSS/DCS Encode & Decode
- 12.5/25 Khz Bandwidth Programmable By Channel
- 5-Tone as Standard
- Advanced 8 Character Invertible Alphanumeric Display
- PC Programmable
- RadioTo Radio Cloning
- BCLO, BTLO, and TOT Functions
- 2 Programmable Soft Keys
- 1 Multi-Position Programmable Toggle Switch
- Voice Inversion Encryption Available
Standard Package Comprises:
- Radio
- Antenna
- FNB-V87 Battery & Charger
- Operating Manual
- 1 Years Warranty
Technical Specifications:
| Specification | VHF | UHF |
|---|---|---|
| Frequency Range (MHz) | 134-174 | 400-470 |
| PLL Steps | 5 / 6.25 kHz | |
| Channel Spacing (kHz) | 12.5/20/25 | |
| No. of Channels | 16 (VX-821E) / 512 (VX-824E/829E) | |
| No. of Groups | 1 (VX-821E) / 32 (VX-824E/829E) | |
| Dimensions (H x W x D) | 96.5 × 57.5 × 37.5mm | |
| Weight | 310g with Antenna, Battery (FNB-V86LI) & Belt Clip | |
| Power Supply | 7.4V DC +20% | |
| Battery Life based on (5/5/90) Cycle |
12.5 hrs (16 hrs w/saver) with FNB-87LI |
11.5 hrs (15 hrs w/saver) with FNB-87LI |
| Operating Temperature Range | -30C to +60C | |
 VX-820 - manuale utente italiano | 4592 kB |
