- Frequency range RX
- 400-430 MHz (UHF Lo version)
430-450 MHz (UHF Mid version)
450-470 MHz (UHF Hi version)
Other bands optional - TX
- 400-430 MHz (UHF Lo version)
430-450 MHz (UHF Mid version)
450-470 MHz (UHF Hi version)
Other bands optional - Modulations RX
- N-FM / W-FM
- TX
- N-FM / W-FM
- Frequency stability
- ±2.5 ppm
- Tuning steps
- Sensitivity
- ＜0.2µV (12dB SINAD)
- Selectivity
- 25 or 12.5 kHz
- Filters
- Receiver system
- IF-frequencies
- Image rejection
- ≥60dB
- Aerial
- 50Ω, SMA
- RF-output
- 4W max
- Audio output
- Memories
- 16 channels in 1 banks
- Power requirements
- 6V DC or internal Li-ion battery
- Current drain RX
- TX
- Manufactured
- Between 200x and 20xx in China
- Dimensions (w×h×d)
- 52 × 112 × 27 mm (2.05 × 4.41 × 1.06 in) not including antenna
- Weight
- 300 gr (10.6 oz) including battery
- Features
- CTCSS / DCS
PC programmable
Time-out Timer
 Puxing_PX-555_user_manual.pdf | 3224 kB |
